Tough Construction
Icom radios are built tough, and the IC-V80/E – Icom's most economical 2M –
is no exception. This military rugged rig offers water resistance and superior protection against dust and dirt (IP54). Compact,
rugged and with plenty of power, the IC-V80/E is ideal for basic, on-the-go ham operations.
750mW loud audio
The
IC-V80/E uses the BTL (bridge-tied load) amplifier that doubles the audio output. Every ham knows that power = current ×
voltage. The V80’s BTL increases the audio output by doubling the voltage delivered to the speaker.The 36mm large speaker
delivers 750mW of loud and intelligible audio*. Great for noisy environments.
Typical value using with internal speaker.
Powerful 5.5W of Output Power
The IC-V80/E
offers a just-right mix of power and size. 5.5 watts of high power will work to get your message through. Get up to 19 hours* of operating time with the Li-ion battery pack (BP-265) or 13 hours with the Ni-MH (BP-264).
All that power comes is an easy to hold and use size – not too big, not too small.
*Typical
operation. 5:5:90 duty cycle with power save on.
IP54 and MIL-STD-810 rugged construction
The dust protection
and water-resistance equivalent to IP54 provides reliable operation for practical outdoor operation. The IC-V80/E tested to
and passed 11 categories of MIL-STD-810 environmental tests.
A total of 207 memory channels
The IC-V80/E has
a total of 207 memory channels, including 200 regular channels, 6 channels, including 200 regular channels, 6 scan edges and
1 call channel. The channel name is programmable with 5 characters for easy recognition.
Built-in CTCSS/DTCS
The
CTCSS and DTCS tone codes provide quiet stand-by and allow you to use tone-access repeaters. The pocket beep alerts you when
a matching tone frequency is received. The tone scan detects the subaudible tone that is used for repeater access.
Internal
VOX function
The IC-V80/E has internal VOX (Voice Operated Transmit) function for convenient hands-free operation with
a compatible optional headset and plug adapter cable. Also, the VOX gain and VOX delay time are adjustable.
Other features
- WX channel and weather alert function (USA version only)
- Program, memory, skip, priority
and tone scans
- Power save function
- BNC type antenna connector
- Automatic repeater function (USA
version only)
- 1750Hz tone for European repeater access (IC-V80E only)
- TOT (time out timer) setting
- Repeater
lockout and busy channel lockout
- PC programmable with optional CS-V80
- Transceiver-to-transceiver cloning
(optional)
- Direct keypad frequency entry
- DTMF memory channels
- Auto power off
- LCD backlight
- Wide/narrow channel spacing
