Basic LTR®/Conventional
mixed mode operation
The IC-F3061 series provides LTR®/conventional mixed mode operation. Group, selective
(DTMF), and phone call are available in LTR® mode.
IP54/55 Dust-protection and splash, water jet resistance
The
IC-F3061 series meets IP54/55 requirements for dust-protection, splash and water jet resistance. Its durable construction
is backed up by the aluminum
die cast chassis and polycarbonate casing, allowing reliable operation under harsh weather
and environmental conditions.
Lithium-Ion battery pack
Supplied 2000mAh Li-Ion battery pack, BP-232, provides
14 hours* of operating time. Icom’s rugged dual-rail guide securely locks the battery
to the radio. Optional battery case BP-240 provides a convenient back up and great reassurance in an emergency.
* Typical operation Tx:Rx:Stand-by=5:5:90, power save on
Most popular signaling built-in
The
IC-F3061 series has built-in 2-Tone, 5-Tone, CTCSS and DTCS signaling capabilities as standard for group communication or
selective calling. 40 pairs of CTCSS/ DTCS memory channels are programmable independent of the operating channels. Also, the
IC-F3061 series can decode ten 2-Tone codes or eight 5-Tone codes on a channel. When a matched tone is received, the following
actions are programmable for each code.
- Beep sound
- Bell icon
- Auto TX
- Answer
back call
- Stun/kill radio
- Scan
Wide frequency range and large channel capacity
The
IC-F3061 series covers a wide frequency range in one version (VHF 136–174 MHz, UHF 400–470 MHz or 450–520
MHz). The 512 memory channel capacity with 128 zones allows you to divide and store a variety of flexible channel groupings.
Memory channel selection can be made with a simple rotation of the rotary channel knob. Wide and narrow channel bandwidth
(25/12.5kHz, 30/15kHz) is also programmable.
Full dot-matrix LCD
Using a large full dot-matrix LCD
(32
× 18 mm), the IC-F3061 series shows upper and lower case characters clearly. The display setting is selectable from
1 line, 12 characters or 2 lines 24 characters via programming. The bottom row shows assigned functions to the [P0] to [P3]
buttons.
Enhanced audio
The IC-F3061 series employs a BTL amplifier that increases the audio output and the
built-in audio compander provides clear, low noise communications.
Voting mode scanning
The Voting mode scanning
detects the S-meter level of repeater stations and automatically selects the strongest station, useful for roaming between
2 or more repeater sites. In addition, the IC-F3061 series has 10 scanning modes including priority scan and double priority
scan.
Built-in inversion-type voice scrambler
The built-in inversion type voice scrambler provides secure conversation
as standard. When a more secure system is required, the 32 code non-rolling-type voice scrambler UT-109R and 1020 code rolling
type UT-110R are available as an option.
Other features
- 8 DTMF autodial memories
- 2 step reduced
power setting
- Power on password
- Busy, repeater lockout functions
- Radio stun and kill functions
disable a lost or stolen unit over the air
- Surveillance function temporarily turns off the LED backlight and beep
sound
- Powerful 5W output both VHF and UHF and more...
- Flash CPU for future upgrade and more...
6.25kHz digital mode ready
A first in the LMR industry.
With the optional UT-119H, the IC-F3061 series provides 6.25kHz digital narrow mode communication that meets the FCC 6.25kHz
emission mask requirements for narrow banding, and increases efficiency of channel allocation and use of spectrum. The IC-F3061
series provides 2 optional slots: one optional slot for the UT-119H digital unit and one for another option board
LTR is a registered trademark of E.F. Johnson Company. All other trademarks are the properties of their
respective holders.
